SCAN 66 series - Dimension Sketch Scan 66-4 Plinth

7
NAVN:
STI:
DIMENSION:
MATERIALE:
DATO:
SIGN:
Krog Iversen & Co A/S
DK-5492 Vissenbjerg
©
TG.NR:EMNE:
C:\Working Folder\Designs\Scan 66\90066004.idw
90066004
Målskitse Scan 66-4 Plint
19-08-2014
hms
Scan 66
VÆGT:
AREAL:
N/A
N/A
171****
337
166****
946,5
434***
799*
185
140
630
380
500
885**
483
366
481
532
Front
Dimension sketch Scan 66-4 Plinth
TECHNICAL DATA
* Centre rear outlet
** Height to the beginning of the connecting
piece at top outlet
*** Fresh air intake at the back of the stove
**** Centre of fresh air intake bottom/
Connecting piece top outlet
