Scania DC12 Work Description

01:03-02
©
Scania CV AB 2011, Sweden
3
Crankshaft Removing the crankshaft...................................... 103
Fitting the crankshaft............................................ 104
Machining crankshafts.......................................... 105
Timing gear .............................................................................. 108
Removing the intermediate gear........................... 110
Fitting the intermediate gear................................. 112
Renewing the bearing in the intermediate gear
for the compressor ................................................ 113
Renewing the bearing in the intermediate gear
for the camshaft .................................................... 114
Removing the camshaft gear ................................ 115
Fitting the camshaft gear ...................................... 116
Removing the crankshaft gear.............................. 117
Fitting the crankshaft gear.................................... 118
Removing the camshaft ........................................ 119
Fitting the camshaft .............................................. 120
Checking the camshaft setting.............................. 123
Lubrication system General ................................................................. 124
Measuring the oil pressure.................................... 125
Oil filter ................................................................ 127
Oil cooler.............................................................. 128
Oil filter unit......................................................... 130
Oil pump............................................................... 135
Turbocharger .............................................................................. 136
Measuring radial and axial clearance ................... 138
Checks after breakdown ....................................... 140
Belt transmission .............................................................................. 141
Contents
www.motodiesel.ir
MASHINESOFT.COM
09120146259

Scania DC12 Specifications

General

Configuration	Inline 6-cylinder
Bore x Stroke	127 mm x 154 mm
Cooling System	Liquid-cooled
Engine Type	Diesel
Displacement	11.7 liters
Weight	Approx. 1100 kg
