Scania DC12 Work Description

01:03-02
©
Scania CV AB 2011, Sweden
125
Measuring the oil pressure
Oil pressure
Special tools
The use of measuring set 99 362 is described in
booklet 01:00-03.
There are two different designs of oil filter.
Idling 1.6 bar
With warm engine running at 1,000 rpm 2.5 bar
With warm engine running at 2,000 rpm 4.5 - 6.0 bar
Number Denomination Illustration
99 362 Measuring set
120 908
Version 1, early model
1 Disconnect the connector from the oil
pressure sensor.
2 Remove the oil pressure sensor and fit the
measuring equipment. Use the union and
adapter according to the illustrations.
OIL
M14x1.5
115 929
14
OIL
115 954
Lubrication system
www.motodiesel.ir
MASHINESOFT.COM
09120146259

Scania DC12 Specifications

General

Configuration	Inline 6-cylinder
Bore x Stroke	127 mm x 154 mm
Cooling System	Liquid-cooled
Engine Type	Diesel
Displacement	11.7 liters
Weight	Approx. 1100 kg
