Scania DC12 Work Description

01:03-02
©
Scania CV AB 2011, Sweden
41
Renewing the valve seats
Special tools
1 Remove the valve seat inserts with an
expanding sleeve from the kit with standard
puller 587 270.
Note: Insert, for example, an aluminium sheet
between the cylinder head and counterhold to
protect against damage.
Number Denomination Illustration Tool board
99 384 Drift D1-A3
99 385 Shank D1-B1
587 270 Kit with standard puller
99 384
110 966
99 385
110 967
2
1
307 223
Cylinder head
www.motodiesel.ir
MASHINESOFT.COM
09120146259

Scania DC12 Specifications

General

Configuration	Inline 6-cylinder
Bore x Stroke	127 mm x 154 mm
Cooling System	Liquid-cooled
Engine Type	Diesel
Displacement	11.7 liters
Weight	Approx. 1100 kg
