INSTALLATION
MANUAL
© Scania CV AB 2018, Sweden
Electrical cables
03:01 Issue 11 en-GB 12
Maximum permissible current and cable length for RK 105°C electrical cable at dif-
ferent cable cross-sections.
Cable cross-section, mm
2
Current, A
1
1. Maximum permissible current under continuous load.
Uf = 2.5% = 0.6 V
Length, m (max)
2
2. For cable lengths above these values the highest permissible voltage drop determines the cross-section.
Uf = 5.0% = 1.2 V
Length, m (max)
b
0.75
3
3. The minimum permissible cable cross-section for electrical cables routed to the engine is 1.5 mm² for single-core cables, and 1.0 mm
for multicore cables.
83.26.4
1.0
c
83.28.6
1.5 16 3.2 6.4
2.5 20 4.3 8.6
4.0 27 5.1 10.1
6.0 36 5.7 11.4
10 51 6.7 13.4
16 70 7.8 15.6
