Scania Radio Medium - Page 42

42
Connector location
Terminal
Function
A
1
CAN_High
2
CAN_Low
3
n.c.
4
Ignition plint 15
5
Ignition_D (wake up)
6
n.c.
7
Battery (12 V)
8
Ground / MINUS
B
1
Tweeter Right Front (+)
2
Tweeter Right Front) (–)
3
Woofer Right Front (+)
4
Woofer Right Front (–)
5
Woofer Left Front (+)
6
Woofer Left Front (–)
7
Tweeter Left Front (+)
8
Tweeter Left Front (–)
C1
1
n.c.
2
n.c.
3
n.c.
4
n.c.
5
n.c.
6
Phone Mute
C2
7
PHONE IN AF+
8
PHONE IN AF–
9
Subwoofer GND
10
Subwoofer Out
11
n.c.
12
n.c.
C3
13
PeriPort Data In
14
PeriPort Data Out
15
Switched Power Supply 12V (for accessories PeriPort)
16
PeriPort Wakeup
17
GND PeriPort
18
PeriPort AF/AUX AF-GND
19
PeriPort AF/AUX AF-IN LEFT
20
PeriPort AF/AUX AF-IN RIGHT
