ENGLISHMultistripper / Multistripper Vario
23
www.scanmaskin.com
Multistripper
Number
Description
Number
Description
1
Connecting arm
40
Insex bolts 6x12
2
Coupling rod
41
Clamping rail
4
Pressure spring
42
Bolt for bearing shank
5
Gear glider
43
Bevel-edged washer M12
6
Gear arm
44
Bearing 6203
7
Ball knob
45
Eccentric shaft
8
Pressure spring
46
Toothed belt pulley 16 t. Ø20
9
Stop ring for pressure spring
49
Oil bronze bearing 20x25
11
Bearing block with bearing
50
Coupling screw
12
Nylon bearing 12x16x30
51
Wheel bearing
13
Gear locking plate
52
Program disc
14
Shim
53
Chain wheel 26 t.
V-15
Rubber handle
54
Chain 8 mm.
V-10-A
Vibration handle, upper
55
Gear stop
V-10-B
Vibration handle, lower
56
Backstop
V-16
Power switch CA10
57
Clamping grip M10, left
V-77
Coupling
58
Retaining washer Ø10
V-17
Cable strain relief PVC
59
Guard complete
18
Rubber cable+plug
60
Toothed belt
19
Blade magazine
61
Toothed belt pulley 16 t. Ø19
V-78
Vibration damper
62
T-key
V-79
Locking bush
63
T-plate
20
Gear shaft
64
Shim
21
Gear VF44 1:70 (-31.04.08)
65
Motor complete
21
Gear VF44 1.60 (01.05.08-)
66
Capacitator
23
Clamping grip M10, right
67
Oil can holder
24
Retaining washer Ø10
68
Micro switch
25
Insex Bolt M5x20
80
Neutral gear wire
26
Retaining washer Ø6
81
Insex bolt M5x16
27
Wheel
82
Oil can
28
Bearing SNR FD204
83
Oil bronze bearing 12x16
29
Neutral gear arm
84
Pulley holder + pulley
30
Crescent
85
Supporting disc Ø20
31
Nylon bearing 20x25 with sleeve
86
M10 bolt 50 mm.
32
Neutral gear disc
87
M10 bolt 45 mm.
33
Tapered gear wheel (pair)
90
Chain adjuster
34
Toothed belt pulley 36 t.
92
Coupling
35
Bearing SAFD204
94
Rubber splash guard
36
Bearing shank/Bushing
95
Angle plate for splash guard
37
Double bearing house
38
Bearing SNR FCE204
39
Front part
