Scansonic DA500 - Controls and Connections; Top View Controls; Back View Connections

2
TOP VIEW
1. Phones jack 8. Volume knob
2. Standby button 9. Mute button
3. FM/DAB button 10. Preset button
4. Auto scan button 11. Info. button
5. Tuning 12. Select button
6. Tuning 13. Menu button
7. Display
BACK VIEW
1. DC input jack
2. Battery door
3. FM antenna
CONTROLS & CONNECTIONS
