6 Situation: 14.06.2005 SDT-0058-00EN
Instruction Manual Electrobloc EBL 225
Before putting the unit into
service for the first time
 Make sure the living area battery is connected.
 Make sure the battery selector switch is set for the correct type of battery.
 Make sure the AES fuse is only used if the AES refrigerator is connected.
Starting up the system
 The system is switched on using the 12 V main switch at the control and
switch panel. Follow the instruction manual of the control and switch panel.
 After switching off the system with the battery monitor or after changing
batteries: Switch on the 12 V main switch on the control and switch panel
briefly to start up the consumers.
Battery selector switch
The switching option provided by the battery selector switch ensures optimum
charging of the two different types of battery, lead acid and lead gel. The
switch must be set to the correct battery type: lead acid or lead gel.
Use a thin object (e.g. a ballpoint pen cartridge) to move the battery selector
switch.
 Set lead gel battery: Set the battery selector switch to "Lead-Gel".
 Set the lead acid battery: Set the battery selector switch to "Lead-Acid".
12 V main switch (on the
control and switch panel)
The 12 V main switch on the control and switch panel switches all consumers
and the panel on and off.
Exceptions:
P
Heater
P
Step
P
Frost protection valve
P
AES/compressor refrigerator
P
Waste water tank heater
P
Awning light
For more information, see the instruction manual of the control and switch
panel.
W Only press the step switch briefly. The PolySwitch fuse may otherwise trig-
ger and interrupt the circuit.
W Danger of explosion by the formation of detonating gas due to an incor-
rectly set battery selector switch, defective batteries, defective Electrob-
loc or an excessively high battery working temperature (more than
30 °C).
W An incorrectly set battery selector switch damages the living area battery.
W Disconnect the Electrobloc from the mains before adjusting the battery
selector switch.
