SDT-0058-00EN Situation: 14.06.2005 5
Instruction Manual Electrobloc EBL 225
4 Suitable accessories (not supplied)
5 Electrical data
6 Operation
6.1 Operating controls
Flat vehicle fuses
The flat vehicle fuses protect the various circuits. This does not apply to the
step.
PolySwitch fuse The "step" output is equipped with a self-resetting PolySwitch fuse.
If there is a fault, e.g. overcurrent, the PolySwitch fuse interrupts the circuit.
After rectifying the fault, the PolySwitch fuse automatically resets after
approx. 1 minute.
The circuit is equipped with a 15 A fuse.
Control and switch panel DT 220, LT 500
Auxiliary charging unit Schaudt battery charging unit type LAS... with up to 18 A charge current
Additional 2-pin charging cable, lengths supplied on request
Solar charge regulator Schaudt solar charge regulator type LR... for solar modules with a total cur-
rent of 14 A incl. 0.5 m cable and plug
Mains connection 230 V AC ±10 %, 47 to 63 Hz sinusoidal, protection class I
Suitable batteries 6-cell lead acid or lead gel batteries of at least 55 Ah
Current-carrying capacity 12 V outputs No more than 90 % of the rated current
of the corresponding fuse may be
drawn, see the block diagram.
W
Blown fuses must only be replaced when the cause of the fault is
known and eliminated.
W
Never bridge or repair fuses.
W
Danger of burning! Blown fuses must only be changed on a zero-cur-
rent Electrobloc.
W
Only use original fuses rated as specified in the instruction manual.
