Instruction Manual for Electroblock EBL 241-2
3
Date: 16.07.2019
8110514 BA / EN
2 Introduction
This instruction manual contains important information on safe operation of
the device. Make sure you read and follow the safety instructions provided.
The operating instructions should always be kept in the vehicle. All safety in-
formation must be passed on to other users.
3 Operation
The electroblock is operated solely from the LT ... operator and control panel
connected. .
Operation on the EBL 241-2 electroblock is not required for daily use.
One-off adjustments only have to be made if the battery type is changed,
during initial start-up or when retrofitting accessories (see Section 3.2 and
the installation instructions for the EBL 241-2).
3.1 Star ting up the system
Y ATTENTION!
Incorrect electroblock settings.
Damage to connected devices. Therefore prior to starting:
F Ensure the leisure area battery is connected.
F Ensure that the battery selector switch (Fig. 4, Pos. 10) is set to the
correct position for the battery installed.
" Use the main 12V switch (see instruction manual of relevant control and
switch panel) to switch on/off all the consumers and the control and
switch panel.
The following outputs are exceptions:
F Step
F AES/compressor refrigerator (only when fuse is inserted)
F Refrigerator controller
These outputs are not disabled from the main switch of the LT ... control pa-
nel.
Please refer to the operating instructions of the LT ... control and switch pa-
nel for further information. .
3.2 Changing the battery
Y ATTENTION!
Use of incorrect battery types or incorrectly rated batteries.
Damage to the battery or devices connected to the electroblock:
F Batteries may only be changed by qualified personnel.
F Follow the battery manufacturer’s instructions.
F Only use the electroblock to connect to 12V power supplies with re-
chargeable 6-cell lead-gel or lead-acid batteries. Do not use any un-
suitable battery types.
