Blue LED 1. LED 2. LED 3. LED 4. LED 5. LED 6. LED 7. LED 8. LED
Battery discharge with: Battery charge with:
> 30A >10A >3A >1A approx.
0A
>1A >3A >10A
Current
The following table shows the interpretation of the current displayed.
Display value for current State of the system
--30A to --1A (negative current) Battery is being discharged
No current (zero point: LED next to
number ”0”)
Battery current is low or 0A
+1A to 10A (positive current) Battery being charged
" Press the ”V ehicle Battery” button once again (underneath the living area
battery symbol, Fig 1, Pos. 5). The display is analogous to the living area
battery (see Fig. 2):
F The ”V olt” symbol lights up.
F The voltage of the starter battery is displayed in the ”Batteries” display
field (left scale, Fig 2, Pos. 2), 12.2V in this example.
Y The display goes out after approx. 20 seconds if no more buttons are
pressed.
The following table shows the correct interpretation of the voltage of the li-
ving area battery displayed on the scale.
These values apply to actual operation, not off-load voltage.
B
a
t
t
e
r
y
Battery operation Mobile operation Mains operation
B
attery-
voltage
Vehicle stationary,
no 230V connection
Vehicle moving Vehicle stationary,
230V connection
Less than 11V
Risk of total
d
i
s
c
h
a
r
g
e
If consumers are
switched off:
battery flat
the alternator is not
charging the battery
The electrobloc is
not charging the
battery
d
i
s
c
h
a
r
g
e
if many consumers
are switched on:
possible battery
overload
12V power supply
overloaded
12V power supply
overloaded
11,5V to 13.0V normal range the alternator is not
charging the
battery
1)
the electrobloc is
not charging the
battery
1)
12V power supply
overloaded
1)
12V power supply
overloaded
1)
13,5V and over occurs only briefly
after c harging
Battery being
charged
Battery being
charged
1)
If the voltage does not exceed this range for several hours.
Measuring the off-load voltage is a simple and effective method of checking
the condition of the battery. Off-load voltage is the voltage of the charged
battery in a passive state, with no current being supplied or drawn.
Voltage
Starter battery
Guidelines for
voltages during
operation
Off-load voltage
