Scheiber BLOC 9 - Technical Characteristics; Electrical Characteristics

Domotique embarquée
Embedded home automation
P. 4
Domotique embarquée
Embedded home automation
BLOC 9
REFERENCE 41.70509.01
POWER SUPPLY 8-32 V DC up to 16 mm2
DETAILS AND FEATURES OF THE INPUTS
- 2 x CAN connectors type 6-way Micro-Fit
- 1 x LIN connector type 4-way Micro-Fit
DETAILS AND FEATURES OF THE OUTPUTS
- 6 adjustable power outputs in current from 3 to 25A.
- 2 x connectors 6-way in 6mm² max.
BYPASS FUSE
(
SUPPLIED
)
15A (blue) 25A (brown)
Check that the cable section is sufcient depending on the size of
the fuse used
LIN BUS To manage up to 6 IBS sensor
CAN BUS 2 x connectors type 6-way Micro-Fit
ENVIRONMENTAL CONDITIONS
Indoor use
Altitude up to 2000m
Operating temperature: 0 to +50 °C
Relative humidity: 0 to 93% - non-condensing
Protection index: IP20
MOUNTING Organize a panel cut-out 84,50 x 125,50 mm and 2 screws support
MOUNTING DISTANCE 138 mm
MECHANICAL ABS Box UL94-V0
WEIGHT 0,19 Kg
STANDARDS EN 60945
FIRMWARE VERSION V7.21 or higher
DIMENSIONS (LxWxH) 150 x 95 x 69,6 mm (with socket mounted)
Technical characteristics
INPUT RATED VOLTAGE
(
VDC
)
8-32 V DC
OUTPUT RATED VOLTAGE
(
VDC
)
equal to the input voltage
SELF
-
CONSUMPTION 60 mA max.
MAXIMUM CURRENT PER OUTPUT adjustable from 3 to 25A
MAXIMUM CUMULATIVE CURRENT 50A
Electrical characteristics
Description of the markings used
V Volt
A Ampere
ou DC Direct current
