Domotique embarquée
Embedded home automation
P. 3
Domotique embarquée
Embedded home automation
Technical specifications
- The luminous intensity of the 6 outputs is dimmable from 20 to 100%. Simply hold the switch button until the desired level is reached.
This feature can be disabled from a Navicolor screen (Optional).
- When the outputs are reactivated after a stop, the selected light intensity before extinction is restored by default.
- Modules have up to 4 active ON or OFF inputs at 0V. These inputs can be used to control outputs directly through wired push buttons.
- An input is dedicated to bloc coding, when used in a CAN MULTIBLOC network
(see accessories / associated references P.2 for coding resistance codes available)
Characteristics
LIGHTING CONTROL MODULE 2.4 GHZ ANTENNA MODULE SWITCH
REFERENCE 41.72119.XX XXXXXX 41.72120.XX XXXXXX 0F.INT221-2.4 0F.INT222-2.4
POWER SUPPLY 8-32V DC with CAN cable - 12VDC Kinetic energy
INPUTS
Up to 4 digital inputs for wired switches
npn type
OUTPUTS 6 outputs - -
MAX.CURRENT PER OUTPUT 5A - -
TOTAL MAX. CURRENT 20A/module - -
DIMMING
Light intensity regulation on each output with
PWM
- -
SUPPLY & OUTPUTS WIRE CROSS SECTION 0.2 to 2.5mm²
CODING & INPUTS WIRE CROSS SECTION 0.2 to 1.5mm²
MAX. NUMBER OF PAIRING
128 (up to 4 pairings on a 2-button switch)
Up to 32 2-button switches / 64 1-button
switches
- -
CONNECTORS
BUS CAN type 6-way Micro-Fit
2-way PicoMax outputs
6-way PicoMax inputs and coding
BUS CAN type 6-way Micro-Fit
Scheiber v8.0 Multibloc Protocol
-
ANTENNA - PCB antenna PCB antenna
FIRMWARE VERSION - 8.00 or higher -
NUMBER OF BUTTONS - - 1 2
TRANSMISSION RANGE - 20m indoor 20m indoor
RADIO STANDARD
/ DEFAULT RADIO CHANNEL
-
2.4 Ghz IEEE 802.15.4 channels 11 … 26
/ IEEE 802.15.4 radio channel 11
2.4 Ghz IEEE 802.15.4 channels 11 … 26
/ IEEE 802.15.4 radio channel 11
DEVICE IDENTIFICATION - - Individual 32 Bit Device ID (factory programmed))
SECURITY - - AES128 (CBC) with Sequence Counter
ENERGY BOW TRAVEL/FORCE - - 1.8 mm / typ. 10 N (at room temperature)
NUMBER OF OPERATIONS AT 25°C - -
typ. 100.000 (tested according to EN 60669 /
VDE 0632)
CERTIFICATION CE CE CE
ENVIRONMENTAL CONDITIONS
Indoor use
Altitude up to 2000m
Operating temperature : 0 to +50°C
Humidity : 0 to 93% without condensation
Indoor use
Altitude up to 2000m
Operating temperature : 0 to +50°C
Humidity : 0 to 93% without condensation
-25°C to + 65°C
ELECTRICAL PROTECTION OF THE POWER LINE Fuse or circuit breaker
PROTECTION CALIBRE
16A if one power line in 2.5mm²
20A if two power lines in 2.5mm²
PROTECTION POSITION accessible and identied for the user
DIMENSIONS
(
LxWxH
)
110 x 77 x 26 mm 146 x 48 x 13.5 80 x 80 x 14.5 mm
MOUNTING DISTANCE
width: 60mm
height: 100mm
vertical position : 50mm
horizontal position : 129mm
WEIGHT 0.120 Kg 0.150 Kg 0.06 Kg
