Scheiber LIGHT AIR SWITCH 43.00009.10 User Manual

Domotique embarquée
Embedded home automation
P. 8
Domotique embarquée
Embedded home automation
Configuration
A. Congure a permanent output
Example of use: connect a reading light equipped with an ON / OFF button
Enter the setting mode (press the L key for 3 seconds)
Choose an output that has not been paired and ashes to designate it as a permanent output
(example: S2).
Press the C key for 2 seconds.
The output ashes quickly, it is now congured as a permanent output.
To exit setup mode, press the L key the number of times required to skip all remaining outputs.
To remove the permanent mode from the output:
Enter the conguration mode and choose this permanent output.
The output ashes quickly: press C until the output goes o.
The output will ash again normally a few seconds later. It is ready to be re-parameterized.
B. Congure the function "turn o everything" with a switch button
Example of use: turn o all outputs by leaving
Enter the setting mode (press the L key for 3 seconds)
On an output of 1 to 5, press the L button for at least 4 seconds (example S2).
The outputs ash alternately.
A. Press the button of the desired switch to assign the all power o function.
C. Congure the function "turn o everything" with switch lock
Repeat steps 1 to 3 of the "turn o everything" conguration above.
B. Press the key of the desired switch twice to assign the function turn everything o + lock
To unlock the switch, press the button assigned above once. Then use your switch normally.
L C
L C
S4
S3
S2
S1
S5
S6
1 2
L C
3
L C
S4
S3
S2
S1
S5
S6
4
L C
1
L C
S4
S3
S2
S1
S5
S6
2
L C
S4
S3
S2
S1
S5
S6
L C
S4
S3
S2
S1
S5
S6
3
OFF
4
B
x2
OFF
4
A
x1
1
2
3
4
1
2
3
1
2
3
4
4

Scheiber LIGHT AIR SWITCH 43.00009.10 Specifications

General

Brand	Scheiber
Model	LIGHT AIR SWITCH 43.00009.10
Category	Switch
Language	English
