D. Congure the extinction of several outputs
Example of use: switch o the ceiling light and various mood lighting,
without switching o the bedside lighting.
Enter the setting mode (press the L key for 3 seconds)
Choose an uncongured output (example S2). S2 ashes.
Assign on the same button an ON, an OFF, and a second ON
(press a third time on the same button)
On another button, assign OFF (this button will be OFF for all desired outputs).
Repeat points 2 and 3 on the desired outputs,
making sure to keep the same button for all OFF.
E. Congure output synchronization
Example of use: the mood lighting is switched on, I want to increase the lighting level by switching
on the ceiling light.
By default, ON synchronization is enabled. To change and set an OFF synchronization, it is
necessary to congure from the Navicolor.
Conditions: several outputs are controlled by the same switch. At least one of the outputs can be
controlled by another button.
Enter the setting mode (press the L key for 3 seconds)
On output 1, for example, assign an ON / OFF on button 1 and an ON / OFF on button 2.
On output 2, for example, assign ON / OFF on button 2.
ON / OFF on button 2 is common to outputs 1 and 2.
If output 1 is on, and you want to turn on output 2, pressing button 2 synchronizes the lights
(output 2 comes on).
3
x3
L
C
L
C
S4
S3
S2
S1
S5
S6
1 2
OFF
4
x1
L
C
1
ON/OFF ON/OFF
2
x2 x2
ON/OFF
3
x2
L
C
S4
S3
S2
S1
S5
S6
L
C
S4
S3
S2
S1
S5
S6
ON
x1
1
2
3
4
5
1
2
3
