3.4 Attached documents
The packaging contains the technical documentation (use and maintenance manual, electric and hydraulic
scheme, warnings and instructions).
ATTENTION
• Lift the system only using the aluminium
structure and not trough the Inox SS fittings.
• Read carefully the use and maintenance
manual before installing the system.
• Use only recommended material for the
installation (especially pipes, fittings and
seals) in accordance with the present
manual.
• Do not store the unit under temperature of 5°
and above 40°C.
DOCUMENTS INCLUDED IN THE PACKAGING (photo is purely for information)
FIG. 3-3
3.5 Technical data
WATERMAKER GROUP
WATERMAKER DIMENSIONS
FIG. 3-4
