Schenker MODULAR 100 User Manual

3 – PRODUCT PRESENTATION COD: 100M12/24.B.2021
EN
THE PRESENT MANUAL BELONGS TO - Schenker Italia - ALL RIGHTS RESERVED
12
Weight: 47 Kg
Hydraulic Connection
Seawater inlet: ¾’’ fitting, 20mm internal diameter reinforced pipe.
Exhaust: ½’’ fitting, 16mm internal diameter reinforced pipe.
Fresh water: ¼’’ fitting, 6x8mm pipe.
PUMP GROUP
Dimensions
Length: 37 cm
Width: 15 cm
Height: 23 cm
Weight: 11 Kg
Hydraulic Connection
Water inlet: ¾’’ fitting, 20mm internal diameter reinforced pipe.
Water outlet: ¾’’ fitting, 20mm internal diameter reinforced pipe.
Feed pump type: Rotative pump
Filters: n. 1 Cartridge filter 5 microns 2.32" x 9 ¾’’
n. 1 Active carbon filter 2.32" x 9 ¾’’
Power supply: 12 VDC +/- 15% (100Z12 version)
24 VDC +/- 15% (100Z24 version)
Average electric consumption: 400 Watt/h average
Nominal fresh water production: 100 Lit/h +/- 20% @ seawater 25 °C salinity 35.000 ppm
CEE conformity: In compliance with directives 89/392 CEE sect.1 (general safety machines
requirements), 89/336 CEE (electromagnetic compatibility), 73/23 CEE
(electric safety requirements)
3.6 Features of the product
The water produced by a Schenker plant, produced from clean seawater has a high purity but the potability
may not be guaranteed as bacterium may be present in the watermaker, caused by non-observance of
shutdown and cleaning procedures. It is essential that correct shut down and storage procedures are followed
to ensure continued purity of the product water. UV treatment of the product water may be beneficial.
