9.3 Using the adapter set (Fig. 4-7)
The adapter set enables the following additional capabilities:
• Using the ball needle to inate balls (20).
• The Dunlop valve (21) enables bicycle tyres and car tyres to be inated.
• Pools, air mattresses, boats or similar swimming accessories can also be lled using the additional conical adapter
(19).
ATTENTION! When inating objects with an air pressure of 10 Psi or less, always inate in short bursts. After each
burst, squeeze the object or use a calibrating measurement device to check whether the required air pressure has
been reached.
ATTENTION! The air pressure required to inate most sports balls is too low to be read out accurately on the device’s
measurement indicator.
10. Operation
m Attention!
Always make sure the product is fully assembled before commissioning!
10.1 Switching on/o󰀨 (Fig. 1)
• Press and hold the On/O󰀨 switch (11) to switch on.
• Press the operating mode button (10) for a short time to switch to the required ination mode.
• Press and hold the operating mode button (10) for 3 seconds until the required measurement unit (bar, kPa, PSI, kg/
cm
2
) is shown on the display.
• Press and hold the On/O󰀨 switch (11) to switch the device o󰀨.
10.2 Selecting ination mode (Fig. 2)
You can choose from four pre-set pressure values: Car, motorcycle, bicycle and ball.
You can also select manual mode and dene the pressure yourself.
Press the operating mode button (10) until the required symbol is shown on the display.
