Scheppach BASA3 User Manual

www.scheppach.com
GB
|
47
15. Special accessories
Special accessories Article number
Transverse cutting gauge 7312 0025
Circle cutting device 7319 0710
Depth stop 7319 0710
Grinding belt device 7319 0710
Table frame 7319 0716
Auto switch-on device type
ALV 2
7910 4010
Auto switch-on device ALV10 7910 4020
Saw bands Article number
for wood:12/0.5/2360 mm, 4
teeth/inch
73190701
Standard saw band
15/0.5/2360 mm, 4 teeth/inch
Straight upright cuts with longitu-
dinal stop
73190704
for wood and plastics:
6/0.5/2360 mm, 6 teeth/inch
73190702
Curving work with small radius
15 mm
12/0.5/2360 mm, 6 teeth/inch
Fine cutting work
73190705
Di󰀨erent materials:
Wood, plastics, metal
3.5/0.5/2360 mm, 14 teeth/inch
Finest cutting work, smallest
radii
73190706
Non-ferrous metal up to 10 mm
6/0.65/2360 mm, 22 teeth/inch
straight cuts and curving work
73190707
• Kinks where the connection cable has been improp-
erly fastened or routed.
• Places where the connection cables have been cut
due to being driven over.
• Insulation damage due to being ripped out of the wall
outlet.
• Cracks due to the insulation ageing.
Such damaged electrical connection cables must not
be used and are life-threatening due to the insulation
damage.
Check the electrical connection cables for damage
regularly. Ensure that the connection cables are dis-
connected from electrical power when checking for
damage.
Electrical connection cables must comply with the ap-
plicable VDE and DIN provisions.
Only use connection cables with the designation
H07RN-F (400 V), H05VV-F (230 V). The printing of
the type designation on the connection cable is man-
datory.
AC motor (Fig. 12)
• The mains voltage must be 230 volts/50 Hz.
• Extension cables up to 25 m long must have a cross
section of 1.5 square millimetres, and those over
25 m long must have a cross section of at least 2.5
square millimetres.
• The mains power connection is protected with a 16
A slow-blow fuse.
Connections and repair work on the electrical equip-
ment may only be carried out by electricians.
Please provide the following information in the
event of any enquiries:
• Engine manufacturer
• Type of current for the motor
• Machine data - type plate
• Switch data - type plate
When returning the motor always send in the com-
plete drive unit with switches.

Scheppach BASA3 Specifications

General

Type	Bandsaw
Table Size	300 x 300 mm
Motor	230 V
Blade Width	6 mm
Cutting Speed	800 m/min
Table Tilt	0° to 45°
