Scheppach Compact 10t Original Instruction Manual

www.scheppach.com
42
|
GB
Motor protection Yes
Phase inverter Yes
Compact 10t
Dimensions D/W/H 830/930/1020
Swivel table height
mm
390
Working height mm 920
Wood length cm 750/1070
Max. power t* 10
400V 230V
Feed speed cm/s 5,4 3,1
Return speed cm/s 24 15,5
Oil quantity l 4,8
Weight kg 134
Drive
Motor V/Hz 400/50 230/50
Rated input
P1 W
3500 3150
Power output P2 kW 2500 2300
Operating mode S6 40% **
Speed 1/min 2800
Motor protection Yes
Phase inverter Yes
Technical changes reserved!
* The maximum achievable splitting force is dependent
on the resistance of the log and can differ due to varia-
ble contributing factors on the hydraulic system.
** Operating mode S6, uninterrupted, periodic opera-
tion
7. Unpacking
• Open the packaging and carefully remove the de-
vice.
• Remove the packaging material, as well as the pack-
aging and transport safety devices (if present).
• Check whether the scope of delivery is complete.
• Injuries due to the workpiece being ejected at high
speed due to improper holding or guiding.
• Hazard due to electrical power with the use of im-
proper electrical connection cables.
• Hazard due to special properties of the wood (knots,
uneven shape, etc.)
• Health hazard due to electrical power, with the use
of improper electrical connection cables.
• Before performing setting or maintenance work, re-
lease the start button and pull out the power plug.
• Furthermore, despite all precautions having been
met, some non-obvious residual risks may still re-
main.
• Residual risks can be minimised if the “Safety infor-
mation” and the “Proper use” together with the oper-
ating manual as a whole are observed.
• Avoid accidental starting of the machine: the oper-
ating button may not be pressed when inserting the
plug in an outlet.
• Keep your hands away from the work area, when the
machine is in operation.
6. Technical data
Compact 8t
Dimensions D/W/H 850/900/990
Swivel table height
mm
390
Working height mm 920
Wood length cm 750/1070
Max. power t* 7,95
400V 230V
Feed speed cm/s 5,4 3,1
Return speed cm/s 24 15,5
Oil quantity l 4,8
Weight kg 126 125
Drive
Motor V/Hz 400/50 230/50
Rated input
P1 W
3500 3150
Power output P2 kW 2500 2300
Operating mode S6 40% **
Speed 1/min 2800
