www.scheppach.com
GB
|
39
7. Unpacking
• Open the packaging and carefully remove the de-
vice.
• Remove the packaging material, as well as the pack-
aging and transport safety devices (if present).
• Check whether the scope of delivery is complete.
• Check the device and accessory parts for transport
damage. In the event of complaints the carrier must
be informed immediately. Later claims will not be
recognised.
• If possible, keep the packaging until the expiry of the
warranty period.
• Familiarise yourself with the product by means of the
operating manual before using for the rst time.
• With accessories as well as wearing parts and re-
placement parts use only original parts. Replace-
ment parts can be obtained from your dealer.
• When ordering please provide our article number as
well as type and year of manufacture for your prod-
uct.
m WARNING!
Danger of choking and suffocating!
The packaging material, packaging and transport safe-
ty devices are not children‘s toys. Plastic bags, foils
and small parts can be swallowed and lead to choking.
- Keep packaging material, packaging and trans-
port safety devices away from children.
8. Assembly / Before commissioning
m Attention!
Always make sure the device is fully assembled before
commissioning!
Your scheppach log splitter is not completely assem-
bled for packaging reasons.
Fitting control arms, Fig. 7
• Lightly grease the sliding plate (5d).
• Insert the control arm (5) with the recess into the
cross-connection (5c).
• Insert M 8 x 30 hexagonal bolt, (5b) with washer
from above, tighten with washer and locknut from
below so that the control arm can still be moved.
• Mount the left control arm 5a in the same way (5c)
Fig.8, also guide the upper rocker switch through the
switch rod recess (5d) Fig.1
6. Technical data
Compact
12t
Compact
15t
Dimensions DxWxH
mm
1160x960x1100 / 1650
Swivel table height mm 320
Working height mm 920
Wood length cm 1070 / 750
Max. power t* 12 15
Hydraulic pressure MPa 23,3 25,6
Cylinder stroke cm 55,0
Feed speed cm/s 5,2 5,2
Return speed cm/s 22 22
Oil quantity l 8,0
Min./max. wood diam-
eter cm
9 – 40
Weight kg 191
Drive
Motor V/Hz 400/50 400/50
Rated input P1 kW 3,5 3,5
Power output P2 kW 2,5 2,5
Input current A 14
Short-circuit resistance
kA
1
Operating mode S6/40% / IP54
Speed 1/min 2800
Motor protection Yes
Phase inverter Yes
Technical changes reserved!
* The maximum achievable splitting force is depend-
ent on the resistance of the log and can differ due to
variable contributing factors on the hydraulic system.
