speed from failure/disorder of the control system relat-
ed to failure in the handles and position of the controls.
Hazards from failure of the control system related to
handle strength, position of controls and marking.
Hazards from break up (chain) during operation related
to saw chain.
Hazards from ejection of objects or uids related to chip
discharge and fuel spillage.
Hazards from dropping the chain-saw while working in
a tree.
RISK OF INJURY !
Contact with the saw-chain can lead to fatal cutting in-
juries.
Never put your hands into the running saw-chain.
RISK OF KICKBACK!
Kickback can lead to fatal cutting injuries.
RISK OF BURNING!
The chain and the guide bar heat up during operation.
Behaviour during an emergency
Start First Aid measures relevant to the injury and re-
quest medical help as quickly as possible. Prevent the
injured person from further injury and keep him/her rest-
ed. For potentially occurring accidents, the First Aid kit,
according to DIN 13164, should always be handy at the
work place. Material taken from the First Aid kit must be
replaced immediately. When you are requesting help,
give the following information:
1. Location of accident
2. Type of accident
3. Number of injured people
4. Type of injuries
Store all safety notices and instructions for the future.
6. Technical data
Machine without guide
bar L x W x H
375 x 182 x 190 mm
Weight without guide
bar and saw chain and
empty tank
5.5 kg
Weight with guide bar
and saw chain and emp-
ty tank
7.0 kg
Cutting Length 47 cm
Guide bar length 51 cm
Automatic chain oiling ja
Saw chain Oil
Special
Saw chain oil
Saw chain oil tank ca-
pacity
260 cm
3
Saw chain division 8,255 mm (0.325″)
Drive link thickness 1.5 mm (0,058”)
Saw chain type
Kangxin .325.058-76
Number of teeths drive
sprocket
7
Tooth pitch of drive
sprocket
8,255 mm (0.325″)
Chain brake yes
Guide bar type
Kangxing BE20-76-5812P
Saw chain speed max. 22 m/s
Motor
1 cylinder
2 stroke
air cooled
Engine capacity 56 cm³
Maximum motor capac-
ity
2,3 kW
Idle speed 3100±300 rpm
Maximum speed with
cutting attachment
11000 rpm
Fuel tank capacity 550 cm
3
Fuel type mix 40:1
Keep the noise emissions and vibrations to a mini-
mum.
• Only use appliances which are in perfect working or-
der.
• Service and clean the appliance regularly.
• Adapt your working style to suit the appliance.
• Do not overload the appliance.
• Have the appliance serviced whenever necessary.
• Switch the appliance o when it is not in use.
• Wear protective gloves.
Measured sound pressure level L
pA
99,6 dB(A)
Uncertainty K
pA
3 dB
Guaranteed sound power level L
wA
114 dB(A)
Measured sound power level L
wA
110,3 dB(A)
Uncertainty K
wA
3 dB
Vibration Front handle 6,72 m/s²
Vibration Rear handle 6,38 m/s²
Uncertainty 1.5 m/s²
7. Before starting up
m CAUTION!: Start the engine only when the saw is ful-
ly assembled.
m CAUTION!: When handling the chain always wear
protective gloves.
Assembling the bar, and the chain
(Fig.3-6)
Open the box and assemble the bar and chain as fol-
lows:
1. Press the front hand guard back (Fig.14/Pos.3a) so
that the chain brake is disabled.
2. Loosen the two nuts (B) and remove the cover (17)
