your country‘s applicable regulations.
The Operating Instructions must always be near the ma-
chine. Put them in a plastic folder to protect them from dirt
and humidity. They must be read by every operator be-
fore beginning work and observed conscientiously. Only
persons who have been trained in the use of the machine
and have been informed of the various dangers may work
with the machine. The required minimum age must be ob-
served.
In addition to the safety requirements contained in these
Operating Instructions and your country‘s applicable reg-
ulations, you should observe the generally recognized
technical rules concerning the operation of woodworking
machines.
General notes
• After unpacking, check all parts for any transport dam-
age. Inform the supplier immediately of any faults. Lat-
er complaints cannot be considered.
• Make sure the delivery is complete.
• Before putting into operation, familiarize yourself with
the machine by carefully reading these instructions.
• Use only original accessories, wearing or replacement
parts. You can nd replacement parts at your schep-
pach dealer.
• When ordering, include our item number and the type
and year of construction of the machine.
HC100dc
Extent of delivery
Compressor HC100dc
2 wheels
2 air lter
1 accessory bag
Operating Instructions
Technical data
Maximum operating pressure,
bars
8
Maximum working pressure,
bars
8
Oil quantity, litres
0,2
Actual air discharge (FAD:
Free Air Delivery) l/min.
272
Suction capacity (PD:
Positive Displacement) l/min
412
Weight kg
44,0
Drive
Motor in V/Hz
230~ / 50
Input W
2200
Speed 1/min.
2850
Sound pressure level L
pA
in
dB:
71,5
Sound power level L
WA
in dB:
93
Subject to technical changes.
