Oil, fig. 4
Warning: It is essential to check the oil level prior to initial
use!
Using the device without oil will lead to irreparable dama-
ges to device and the warranty will be void.
1 Remove the plastic oil inlet plug (14) on the top of the
compressor housing’s crankcase.
2 Fill the oil into the crankcase until the oil level in the
glass sight gauge (16) has reached the centre point of
the red circle.
3 Replace the new oil inlet bolt (14) included in the
delivery and tighten it securely.
Air filter, fig. 5
Warning: The air filter must be installed before the initial
use. Using the device without air filter will damage the
compressor and void the warranty.
The air filter (15) is attached on the right side of the cylin-
der and screwed tightly.
Start-up
Warning:
Prior to initial use, the oil level must be checked!
1 Ensure the mounting location of the compressor is
clean, dry and well ventilated.
2 Make sure the oil level is correct and the air filter has
been mounted.
3 Start the compressor as described in section “Switching
the compressor on and off”. If compressor is switched
on for the first time, let the compressor run without
load and with open drain valve for ten minutes so that
all components are well lubricated.
Warning: Since compressed air is escaping from the out-
let, the outlet must not be directed towards the machine
operator or persons in the surrounding area. The air emit-
ted by the device must not be inhaled. Check the pressure
control valve every day.
Switching the compressor on and off, fig. 6
1 Check the type plate on the compressor: 230 - 240 V
(or 110 – 120 V).
2 Plug the compressor cable into a standard mains socket
(240 V or 120 V) and switch the device on.
3 To turn the compressor on, lift the ON/OFF switch (3)
at the pressure switch cover (2).
4 Push the ON/OFF switch down to turn the compressor
off.
