international 59
Vaihtovirtamoottori, Kuva 12
Verkkojännitteen tulee olla 230 V / 50 Hz.
Enintään 25 m pitkän jatkojohdon vähimmäishalkaisi-
jan tulee olla 1,5 mm2, ja yli 25 m pitkän jatkojohdon
vähimmäishalkaisijan tulee olla 2,5 mm2.
Verkkoliitäntä suojataan 16 A:n hitaalla sulakkeella.
Anna seuraavat tiedot tiedustelujen yhteydessä:
moottorin valmistaja
moottorin virtalaji
koneen tyyppikilven tiedot
kytkimen tyyppikilven tiedot Liitä moottoria palauttaes-
sasi lähetykseen aina koko käyttöyksikkö kytkimineen.
Tärkeät varaosat
Tuote Tuotenumero
Höylänteräsarja = 2 kpl 390 2202 701
Moottori 230 V 390 2202 010
Kytkin 230 V 390 2202 011
Lattahihna 390 2202 012
Motor de corriente alterna (Fig. 12)
El voltaje de la alimentación de ser 230 Voltios/50
Hz.
El cable prolongador debe tener una sección de cruz
de 1,5 mm2 para cables de hasta 25 m de longitud y
al menos 2.5 mm2 para longitudes de más de 25 m.
El cable de alimentación está asegurado con 16 A.
Si tiene preguntas, por favor proporcione la siguiente in-
formación:
Fabricante del motor
Tipo de corriente utilizada por el motor
Datos de la placa de identificación de la máquina
Datos de la placa de identificación del interruptor
Si vuelve el motor siempre tiene que enviar el dispositivo
completo con el interruptor.
Piezas de repuesto importantes
Artículo Artículo - Número
Conjunto de hoja de Cepilladora
/Regruesadora = 2 piezas 390 2202 701
Motor 230V 390 2202 010
Interruptor 230V 390 2202 011
Correa plana 390 2202 012
