www.scheppach.com
GB
|
29
Attention! Depending on how you will use the tool, the
actual values may deviate from the indicated values.
Take measures to protect yourself from noise pollution.
In this process it is important to take the complete se-
quence of operation into account. This also includes
moments during which the power tool operates without
-
ble measures comprise amongst other things regular
maintenance and service of the tool and the insertion
tools, regular breaks and the appropriate planning of
the sequences of operation.
7. Unpacking
• Open the packaging and remove the device care-
fully.
• Remove the packaging material as well as the pack-
• Check that the delivery is complete.
• Check the device and accessory parts for transport
damage. In the event of complaints the carrier must
be informed immediately. Later claims will not be
recognised.
• If possible, store the packaging until the warranty
period has expired.
• Familiarise yourself with the product by means of the
• With accessories as well as wearing parts and re-
placement parts use only original parts. Replace-
ment parts can be obtained from your dealer.
• When ordering please provide our article number as
well as type and year of manufacture for your equip-
ment.
m ATTENTION!
The device and packaging materials are not toys!
Children must not be allowed to play with plastic
bags, lm and small parts! There is a risk of swal-
lowing and suocation!
8. Before commissioning
m ATTENTION!
Always make sure the device is fully assembled
before start-up!
Wheel kit (g. B + C)
To manually change the position of the plate compac-
tor, it can be equipped with the enclosed wheel kit.
6. Technical data
Motor / Engine
1-cylinder 4-stroke
OHV Motor
Displacement 196 cm³
Motor power 4,8 kW / 6,5 HP
Tank volume 3,5 l
630 x 400 mm
Compaction pressure 30 kN
Travel speed 25 m/min
Vibration strokes 4300 1/min
Compaction depth 40 cm
Max. permissible angle of
the motor
20°
Weight 125 kg
Noise and vibration
m Warning:
wear suitable hearing protection.
Noise characteristic values
Sound power level L
WA
Sound pressure level L
pA
Uncertainty K
wa/pA
Vibration characteristics
Vibration a
h
30 m/s²
Note: The indicated sound levels have been deter-
mined according to a standardized testing procedure
other. Furthermore, these values are suitable to eval-
uate the loads that sounds can cause for the user in
advance.
