english 7
Manufacturer:
Scheppach Fabrikation von Holzbearbeitungsmaschinen GmbH
GÜnzburger Straße 69
D-89335 Ichenhausen / BRD
Dear customer,
we wish you a pleasant and successful working experience
with your new scheppach wet grinding machine.
According to the applicable product liability
law the
manufacturer of this device is not liable for damages which
arise on or in connection with this device in case of:
• improper handling
• non-compliance with the instructions for use
• repairs by third party, non authorized skilled workers
• installation and replacement of non-original spare parts
•
improper use
• failures of the electrical system due to the non-
compliance with the electrical specifications and the
VDE 0100, DIN 57113 / VDE 0113 regulations
Recommendations:
Read the entire text of the operating instructions prior to the
assembly and operation of the device.
These operating instructions are intended to
make it easier
for you to get familiar with your device and utilize its in-
tended possibilities of use.
The operating instructions contain important notes on
how to work safely, properly and economically with your
machine and how to avoid dangers, save repair costs,
reduce downtime, and increase the reliability and working
life of the machine.
In
addition to the safety regulations
contained herein, you
must in any case comply with the applicable regulations of
your country with respect to the operation of the machine.
Put the operating instructions in a
clear plastic folder to
protect them from dirt and humidity, and store them near
the machine. The instructions must be read and carefully
observed by each operator prior to starting the work. Only
persons who have been trained in the use of the machine
and have been informed on the related dangers and risks
are allowed to use the machine. The required minimum
age must be met.
In
addition to the safety notes
contained in the present
operating instructions and the special regulations of your
country, the generally recognized technical rules for the
operation of wood working machines must be observed.
General Notes
• When you unpack the device, check all parts for possible
transport damages. In case of complaints the supplier is
to be informed immediately.
• Complaints received at a later date will not be
acknowledged.
• Check the delivery for completeness.
• Read the operating instructions
to make yourself familiar
with the device prior to using it.
• Use only original parts for
accessories as well as for
wearing and spare parts. Spare parts are available from
your specialized dealer.
• Specify our part numbers as well as the type and year of
construction of the device in your orders.
Safety Instructions
Information relating to your safety are highlighted with this
symbol in the present operating instructions.
Operators’ Training
• Pass the safety instructions to all persons working with
the machine.
• The operator must be at
least 18 years old. Trainees
must be at least 16 years old, but are only allowed to
use the machine under supervision.
• Persons operating the machine must not be distracted.
• Keep away children from
the machine if it is connected
to the mains.
• Always wear tight clothes. Remove
jewelry, rings, and
wrist watches.
• Observe all safety instructions and
warnings on the
machine and maintain them in a readable state.
• Be careful when working with
the machine: the rotating
grinding tool may cause injuries of fingers and hands.
Stability
• Make sure the machine is installed on a firm ground with
sufficient stability.
• Make sure the workplace is sufficiently illuminated.
Mains Connection of the Machine
TiGer 2000 TiGer 2500
Scope of delivery
Grinding stone Grinding stone
Universal holder Universal holder
Abrasive paste Abrasive paste
Angle measurer 200 Angle measurer 250
Leather honing disc Leather honing disc
Operating
instructions
Operating
instructions
Specifications
Dimensions
LxWxH mm
348 x 285 x 270 348 x 328 x 335
Tool rest
ø mm
12 12
Grinding
stone ø mm
200/12 x 40 250
Idle-running
speed
- grinding
stone 1/min.
120 90
Cutting
speed m/sec.
1,2 1,2
Weight kg
13,5 20
Drive
Motor V
220 – 240 220 – 240
Input P1 kW
120 200
Output P2
kW
60 100
Motor speed
1/min.
1200 1335
Operating
mode
S6 40 % S1 100 %
Current
rating A
0,6 0,93
Subject to technical modifications!!
