Schertler DAVID X - Rear Panel Features; Power Switch and Ground Lift; Mains Power Connection Details

9
Class–A High Voltage Preamp / No Integrated Circuits / No NFB
SWISS
MADE
1 3
INSTRUMENT IN STEREO IN
2
10V GAIN WARM LOW MID HIGH REV VOLUME
MASTERDI OUT
GAIN RESON LOW MID HIGH REV VOLUME
flat
INSERT REVERB
master
LINE OUT
DAVID X
GND LIFT
INSTRUMENT INMIC IN P24 10V
DAVID X
1 2 0 W A T T
A C O U S TIC
A M PLI F I E R
SER IAL NUMBE R
WWW . S C H E R T L E R . C O M
M
A
D
E
+
S
W
I
S
S
8 0 W A T T P O W E R C O N S U M P TIO NX S E R I E S
CAUTION
RISK OF ELECTRIC
SHOCK
DO NOT OPEN
TO REDUCE RISK OF FIRE,
DO NOT EXPOSE THIS
EQUIPMENT TO RAIN
OR MOISTURE. FOR
CONTINUED PROTECTION
AGAINST RISK OF FIRE,
REPLACE ONLY WITH THE
SAME TYPE AND RATING
OF FUSE.
240 Hz
150 Hz
5.1
5.2
5.3
REAR PANEL
5.1. POWER ON/OFF: System ON/OFF switch.
5.2. GROUND LIFT: This switch connects and disconnects the ground.
5.3. MAINS POWER CONNECTION:
Connection to mains Fuse carrier
220 - 230 V~ 50 Hz / 60 Hz T 1.6 A L 250 V
240 V~ 50 Hz T 1.6 A L 250 V
120 V~ 60 Hz T 3.15 A L 250 V
100 V~ 50 Hz / 60 Hz T 3.15 A L 250 V
PLEASE ENSURE THAT THE CORRECT VOLTAGE IS OBSERVED
AND THE ORIGINAL CONNECTION CABLE IS USED
