Schiit LYR - Back Panel Overview

SCH03D
000001
230VAC 45W
IN OUT
dynamically adaptive
ZERO FEEDBACK
noninverting HYBRID
headphone amplifier
caution: risk of electric
shock— do not open.
no user serviceable
parts inside
no user serviceable parts inside
not muted—turn Lyr
on at least 20 seconds
before turning on your
power amp, and turn
your amp off before
you turn off your Lyr.
3 On-Off Switch. Up
is on. Down is off. For
best tube life, turn Lyr
off when you’re not
going to use it for an
hour or two.
1 RCA Inputs.
Connect to your music
source here. You can
even use a fancy
audiophile cable if
you like.
2 Preamp Outputs.
Lyr can be used as a
high-quality preamp.
Please note that the
preamp outputs are
BACK PANEL
4 AC Input. Plug the
power cord in here.
Plug the other end into
a wall outlet of the
correct voltage. Trying
to run a 115V unit on
230V will result in a
blown fuse, no music,
and a void warranty.
5 Disclaimer. No,
seriously. Don’t take
this apart. Don’t stick
paperclips through
the holes on the top
or side. There are
seriously dangerous
voltages inside, and we
don’t want you to die.
1
2
3
4
5
