1 RCA Outputs. Connect Mani 2’s RCA outputs to
your preamp or headphone amp.
2 Ground. Connect the turntable ground to Mani
2’s ground input, if you have hum problems.
3 RCA Inputs. Connect Mani 2’s RCA inputs to
your turntable, using short, shielded cables.
4 Power Switch. Turn on to enjoy your turntable.
But see VERY IMPORTANT to the right.
5 Power Input. Connect the supplied 16VAC wall-
wart to Mani 2 with the attached cord.
CONNECTIONS
VERY IMPORTANT:
Turn on Mani 2 FIRST, before other components
like power amps, or else you may get some very
loud pops through your system.
Turn Mani 2 off AFTER turning off power amps,
for the same reason. (Or just go ahead and leave
it on, that’s ne too.)
DO NOT change gain switch settings with Mani 2
on. Turn your whole system off, change gain, and
then turn on Mani 2 rst, before anything else.
1 2 3 4 5
