CONNECTIONS
B
USB
COAX
BNC
AES/EBU
OPTICAL
SCH10Y
000001
115VAC 45W
4 Toslink Input.
Connect with a short (3m or less) Toslink
cable to any optical digital output.
5 Coax Input.
Connect to any coaxial digital source with a
high-quality 75 ohm coaxial cable.
6 BNC Input.
Connect with a good, 75 ohm coaxial cable
to a BNC digital source.
1 Single-Ended Output.
Connect to your preamp or integrated amp
with good RCA cables.
2 Balanced Output.
Connect to your balanced gear with good
XLR cables.
3 USB Input.
Connect to your computer source with a
short (2m or less), USB 2.0-rated cable.
7 AES/EBU Input.
Use a high-quality XLR cable to connect to
any AES/EBU digital source.
8 Power Switch.
Up for on, down for off. Very simple.
9 Power Cord.
Plug the end of the supplied IEC cord in here,
and hte other end into the wall. Yep.
1 2
3
4 5 6 7
8 9
