Closing the HandPunch
Before closing the HandPunch clear all dust and debris away from the HandPunch. With
the wall mount latch in the unlocked position, swing the body of the HandPunch up and
lock the latch into place with the key provided with the HandPunch (see Figure 6-1).
Dust and debris surrounding the HandPunch can drastically affect the terminal’s
operation. It is important to ensure the HandPunch is free from dust and debris before
closing the terminal.
Do not force the HandPunch onto the wall mount latch when the latch is in the locked
position.
No
Recognition Systems Inc.
LOCK
Key
L atch
Wall Plate
Key
L atch
Wall Plate
Unlocked Position
Locked Position
Figure 6-1: Closing the Handpunch
