Appendix B
Noted Board Configuration Differences
Because of Schlage Biometrics’ camera retrofit of the HandPunch some changes have
been made to the main PCB and they are listed as follows:
• Dipswitches have been removed
- memory is reset with a push-button reset and user interface with keypad and LCD
• Power has moved to the right side of the PCB
• The RS-232 RJ-45 receptacle has been replaced with a 4 pin Molex connector on the
left side of the PCB
• A 2 pin Molex connector (J5) has been added to the board, next to the reset button,
to supply power for the LEDs. This connector should never be unplugged. unless a
modem or Ethernet is added to the PCB
• The upgrading of the memory is now handled through software codes at the
HandPunch. Contact Order Entry for memory upgrades
To reset the memory of the HandPunch follow these steps-
1. Remove power and battery jumper, if a back up battery is installed
2. Press down on reset button and apply power
3. Release button
4. Reader will boot to
ERASE :1 SETUP
:9 ALL!!!
• Press 1 to erase setup i.e. address, outputs, passwords, but retain user database and
datalogs
• Press 9 to erase everything i.e. HandPunch goes back to factory defaults
Memory Reset
