Schlumbohm EndoPilot - Description of the individual components

EndoPilot
*related to the additional module “CoPilot” - 1 - 609 2201 v12 www.schlumbohm.de
Description of the individual components
Picture Component Description
1
Control-Unit
Ref.-No: 109 2010
Control unit with touch screen, incl. 4 connecting sockets (1a, 1b,
1c, 1d) and tripod nut on the backside
2
Power Supply
Ref.-No: 109 232.1
AC/DC converter with Euro-prime plug
Input: 100 – 240 V/AC Output: 12 V/DC 1,25 A
3
Foot Switch
Ref.-No: 109 233.4
Start/stop, cable-connected foot switch with connection to the
power supply
4
Apex-cable set
Ref.-No: 109 2311
4a – Measuring cable with plug Ref.-No: 109 2312
4b – Cable with file clamp Ref.-No: 109 2313
4c – Lip clip Ref.-No: 109 2314
5
Contra-angle
Ref.-No: 109 0126
For the Apex-measuring / fully isolated/ transmission 1:1, with ISO-
E fitting
6
Motor
Ref.-No: 109 0112
Motor with Apex-measuring contact, LED performance display and
ISO-E connection
7
D-Pack Heating Tip
Ref.-No: 109 0152 - ...56
Heating Tips - 5 different sizes are available
8
D-Pack
Ref.-No: 109 0151
DownPack handpiece with LED display
9
BackFill Needle
Ref.-No: 109 0149
The Gun Needle Starter Set encloses 3X25ga und 3X 23ga
Different sizes are available
10
Heat insulator
Ref.-No: 109 0143
Offers protection from thermal damaging
11
-
BackFill Gun
Ref.-No: 109 0141
(Backfill cable)
Ref.-No: 509 0142
For the thermo-plastic filling of the root canal
(cable: no illustration)
11a – Release button
11b – Piston
11c – Lever
11d – Cylinder with knurled knob
12
Multi-tool
Ref.-No: 109 0147
For forming as well as screwing on and off the BackFill Needles
13
Guttapercha
Ref.-No: 109 0142
Pellets made of Guttapercha for the BackFill Gun
Gutta Percha Bar encloses 100 Pellets
14
Cleaning Set
Ref.-No: 109 0148
Brushes for the cleaning of the BackFill Gun
The Cleaning Set encloses 2 brushes
19
Base with equipment Holder
Ref.-No: 109 2306
Tray for the entire equipment (see illustration on page 2)
-
Protective Foil
Ref.-No: 109 2397
Foil for protection of the display (optional, no illustration)
Can be ordered from the manufacturer
-
Wireless foot switch
Ref.-No: 109 2360
Special accessories: wireless foot switch with one pedal (single)
incl. receiver module
(optional, no illustration )
