PRODUCT DESCRIPTION
30.30.01.00174/06 www.schmalz.com EN | 15
2 Product Description
2.1 Components of the vacuum tube lifter Jumbo
The vacuum tube lifter JUMBO consists primarily of the following components:
Item
Name
Item
Name
1
Vacuum generator / depending on
equipment
6
Suction pad
2
Suspension eye
7
Ejector
3
Rotary union
8
Pressure reduction valve
4
Lifting unit
9
Pump
5
Operator handle
10
Motor protection switch
The components of the system may not be opened or modified for the entire
warranty period. Opening the components, or making modifications or mechanical
changes to the components, voids the warranty.
10
2
3
4
8
5
6
1/7
1/9
