Schmalz Jumbo Flex 35 - 5.5 Final System Test

INSTALLATION
30.30.01.00174/06 www.schmalz.com EN | 31
DANGER
Gripping the supporting surface
Personal injury / damage to plants/systems
►
Ensure that the tube lifter cannot grip the supporting surface when in its lowest
position.
Minimum clearance: 10 cm
5.5 Test
Installation of the vacuum tube lifter Jumbo is complete following 3-4 successful
test runs using a workpiece. The checks required in Europe before initial use in
accordance with EN 14238 are covered by a type test.
Minimum distance to the
floor 10 cm
