5
Capacity (weight mode): 300 g
Capacity (area weight mode): 30 000 g/m²
Sample size: 100 cm²
Resolution (weight mode): 0.01 g
Resolution (area weight mode): 1g/m²
Accuracy (weight mode): ± 0.01 g
Accuracy (area weight mode): ± 1 g/m²
Platform size (mm): 120 ø
Power supply: Rechargeable battery DC 9 V/500 mA
12 h continuous use, 10 h charging time
AC adapter: 100 - 240 V AC - 50/60 Hz
Temperature range: 15 - 40° C
Air humidity: 85% RH, max.
Weight (net / gross): Approx. 1.7 kg / 2.7 kg
Dimensions (mm): 211 L x 185 W x 59 H
2 Specifications
Balance
1 AC adapter, 100 - 240 V
1 Calibration weight 200 g
1 Operating Instructions
Test certificate not available.
2.1 Delivery Includes
2.2 Unpacking and Assembly
- Unpack the EAR-300.
- Inspect the EAR-300 for any shipping damage.
Should you find any damage, immediately notify
the vendor.
Notices of defect must be filed immediately,
in writing, at the latest within 7 days on receipt
of the goods.
Assembly:
- Remove the rubber cap from the weighing shaft
- Carefully press the support plate 12 onto the
weighing shaft 13.
- Mount the support plate with the hexagon socket
screw by using the hex-wrench with max. 0.2 Nm.
- Place the sample platform 11 on the support
plate.
Removal:
- To remove the sample platform 11 and the
support plate 12 proceed in the reverse
order.
11
12
13
The support plate must be removed for transport to avoid damage of
the balance.
