Schmidt MV3 - Recommended Spare Parts Lists

69
Copyright © 2021 Axxiom Manufacturing, Inc.
MV3 Valve Abrasive Blaster Spare Replacement Parts List
A) ELECTRIC and PNEUMATIC CONTROLS (see note below & refer to Section 9.0 drawings)
Item No.
Qty.
Part No.
Description
2
1
42XX-10X
Air Inlet Crowfoot (specify piping size)
2
10
42XX-999
Crowfoot Gasket (specify piping size)
3
1
2401-50X
Air Inlet Ball Valve (specify piping size)
4
1
2223-000
ComboValve®
4
2
2223-000-99
Repair Kit, ComboValve
5
1
2100-010-04
Popup Head with High Flow Stem
6
1
2100-011-04
Popup Gasket, SureSeal (skirted)
8
1
2401-502
Drain ball valve, 1/4"
9
1
4115-005-XX
Blowdown hose assembly (specify vessel size)
10
1
4104-40X-XX
Blast hose assembly (specify size and length)
11
1
500X-XXX
Blast nozzle (specify size and type)
13
1
2401-50X
Choke Ball Valve (specify piping size)
14
1
2128-10X
MV3 Valve (specify piping size)
14
1
2128-100-98
MV3 Valve replacement parts seals kit
14
1
2128-100-99
MV3 Valve replacement parts kit
14
1
2128-00X-10
MV3 Valve Base, (specify piping size)
21
1
2014-300
Breather vent, 1/8”
22
1
7000-001-11
Handway crab assembly, 6” x 8”
25
2
4215-XXX
Nozzle Holder (specify size and type)
26
2
4213-XXX
Blast Hose Coupling (specify size)
27
2
4214-108
Threaded coupling (specify size and type)
27
20
4214-999
Coupling Gasket (fits hose and threaded couplings)
34
2
7000-001-18
Handway Gasket, 6” x 8” (SureFit™)
36
2
4205-10X
Hose insert (specify size)
36
10
4205-10X-99
Insert gasket
37
2
4235-00X
Hose clamp, double bolt (for field installation) (specify size)
38
10ft
4102-00X
Air hose (specify size)
39
20
7119-002
Safety Pin, Air/Blast Hose Coupling
40
2
8710-98778
Hose whip check
41
1
7031-999-02
Safety decal kit (See Section 0.0)
-
1
2408-907
Union end ball valve (optional) See Section 5.13
B) ITEMS FOR PNEUMATIC CONTROLS ONLY (see note below)
Item No.
Qty.
Part No.
Description
12
1
2263-002
Pneumatic Deadman Valve (specify type)
12
2
2263-002-99
Pneumatic Deadman Valve Replacement Parts Kit (specify type)
15
1
4100-501
Twinline Hose, 55ft.
C) ITEMS FOR ELECTRIC CONTROLS ONLY (see note below)
12
1
2263-402-01
G2E Electric Deadman Switch with Plug
15
1
7074-055
Extension Cord 55'
16,19
1
7109-300
Female Twist-lock Connector, 3-Prong
17,18
1
7109-301
Male Twist-lock Plug, 3-Prong
20
1
2229-100
Electric Control Valve, 12Vdc
20
2
2229-100-99
Electric Control Valve Replacement Parts Kit
20
1
7112-000
Power tee, 12Vdc with coil and connectors
35
1
2013-402
Dust Eliminator, 1/4"
NOTE: Determine the type of blast controls on the abrasive blaster (either electric or pneumatic). Then, the
required list of spare parts is List “A” plus either List “B” or “C”. Example: If your abrasive blaster has
pneumatic controls then the recommended spare parts you need are those items included in List “A” and “B”.
For blasters with special options refer to supplemental drawing(s) included with this operation and maintenance
manual.
10.0 Recommended Spare Replacement Parts Lists
