STEUEREINHEIT AIRBASIC 2 –GEBRAUCHSANWEISUNGEN
AIRBASIC 2 CONTROLLER – USER MANUAL
47
5.4. Shutdown Faults
The shutdown faults in the controller are designed to protect the compressor from component failure or extreme
environmental conditions. These alarms will stop the compressor and/or inhibit its start-up. To reset an alarm
message, eliminate the cause of the concern and press Reset.
See the following table for shutdown faults that can occur in the AirBASIC2 Controller
Shutdown faults
Code Meaning
A01 high oil temperature
A03 motor thermal overload relay trip
A04 phase inversion/phase loss
A05 emergency stop button open
A07 temperature probe is faulty
A12* high pressure alarm; pressure higher than P01
A13* pressure transducer is faulty
A26 set data loss and acquisition of default data
A33 power failure (only applicable if automatic restart is disabled)
A34 low oil temperature
*Note!: to apply only the controller in mode with pressure transducer
