SCHUBERTH E1 - Inner Lining; Removing the Lining; Mounting the Crown Liner

EN
3. Pull the plastic bar out of the mounting
and remove the crown liner.
MOUNTING THE CROWN LINER
The sewn-in plastic bar on the forehead section and the retention aps
in the neck area are used as mounting assists.
1. Push the plastic bar piece by piece
below the notches on the plastic bar
axed to the inner shell.
2. Insert the plastic retention aps with
round holes over the pins sewn into the
rear section of the cheek pad and ax
them using the red snaps.
14. INNER LINING
The replaceable inner lining of the E1 is washable and ensures both an excel-
lent t and improved ventilation of the helmet.
The high-comfort cheek pads ensure that the helmet ts comfortably
around the cheeks, and the headband pad provides an optimal t all around
the head. The head pad sits comfortably on the head without covering the
ventilation channels.
The internal lining consists of skin-friendly materials throughout, particularly
in areas that come in contact with the head. These are a soft, breathable
COOLMAX
®
material that transports heat and moisture very well, a special
noise-reducing Polygene
®
material with antibacterial properties and a sweat-
absorbing Interpower
®
material.
REMOVING THE LINING
1. Undo the snaps on the front straps of
the neck collar and pull the neck collar
out of the mounting by pulling strongly
inwards.
2. Undo the two rear snaps of the
cheek pads as well as rear crown liner
retention ap button.
C. THE HELMET
