MAINTENANCE
FX-520 06/16 Maintenance Section 5-21
© 2016 Alamo Group Inc.
MAINTENANCE
It is critical that the driveline clutch slip when an obstacle or heavy load is encountered to avoid mower and/or
tractor damage. If the mower sits outside for an extended period of time or is exposed to rain and/or humid air,
the clutch lining plates must be inspected to ensure they are not frozen together from rust or corrosion. If the
mower has been exposed to such conditions, at the start of each mowing season, and any time it is suspected
that the slip clutch plates may be frozen together, readjust the slip clutch as detailed in Slip Clutches of the
maintenance section in this manual.
When disconnecting from the tractor for short period of time, swing the PTO support upright and lay the PTO
driveline into the cradle. When storing the mower for an extended period of time, it is recommended the
driveline be removed from the machine and stored inside.
When connecting the cutter to the tractor, ensure the PTO support is swung down, and out
of the way.
PROPER TORQUE FOR FASTENERS
The chart lists the correct tightening torque for fasteners. When bolts are to be tightened or replaced, refer to
this chart to determine the grade of bolts and the proper torque except when specific torque values are
assigned in manual text.
RECOMMENDED TORQUE IN FOOT POUNDS UNLESS OTHERWISE STATED IN THE MANUAL*
NOTE: These values apply to fasteners as received from supplier, dry or when lubricated with normal engine
oil. They do not apply if special graphited or molydisulphide greases or other extreme pressure lubricants are
used. This applies to both UNF fine and UNC coarse threads..
Never allow children to play on or around Tractor or Implement. Children can slip or fall off
the Equipment and be injured or killed. Inadvertent contact with controls can cause the
Implement to shift or fall crushing themselves or others.
(SG-25)
