TABLE 6.1 - TECHNICAL FEATURES
6. TECHNICAL FEATURES
1. Paint regulator
2. Spray nozzle
3. Actuating trigger
4. Material volume regulator
5. Air  lter cover
6. Electric cord
7. Reservoir
8. Hose
9. Spray gun support
10. On / Off switch
11. Wheels
12. Carry handle
MODEL
Power
W
Voltage
V
Current
A
Frequence
Flow
l/min.
Maximum
Viscosity
DIN/s
Reservoir
Capacity
ml
Ø nozzle
mm
Noise level
dB(A)
Vibration
level
m/s²
Approx.
weight.
Air Plus Spray
Schulz
250
127 2,8
60Hz
700 50
1000
2,5
80 2,5
1,4
220 1,5
450
127 3,6
700 35 1,4
220 2,1
600
127 4,8
200 40 1,0 2,6
220 2,8
700W
127 5,6
1200 50 800 2,5 4,5
220 3,2
FIGURE 7.2 - 600W
FIGURE 7.1 - 250W, 450W
FIGURE 7.3 - 700W
1
6
2
3
8
5
4
8
4
3
5 12
9
7
11
6
2
2
7
7
1
1
4
10
12
7. MAIN COMPONENT PARTS AND THEIR FUNCTIONS
