12. Never clean the equipment with solvents or any other ammable substances, use a neutral detergent.
Consult the PREVENTIVE MAINTENANCE chapter.
13. If power failure occurs during equipment use, turn off immediately using the product’s on/off switch
and return the equipment to its starting position. If any object is in contact with the saw, inspect it and remo-
ve the saw (if damaged, replace it immediately) before restarting the machine.
14. In the presence of any abnormality, immediately suspend its operation and contact the nearest SCHULZ
AUTHORIZED DEALER
15. Besides the care recommendations presented here, consult the MAIN COMPONENTS chapter.
6. TECHNICAL FEATURES
TABLE 6.1 TECHNICAL FEATURES
MODEL POWER INPUT:
RATED VOLTAGE/
FREQUENCY:
NO LOAD SPEED: SAW BLADE:
TABLE TILTING
RANGE
MITER CUTS:
TABLE SAW
POSITION
MITRE SAW
POSITION
Mitre Saw 8’’ 1200W
127V ~ 60Hz
4500 RPM Ø210 x Ø30 x 2,5mm -45º/0º/+45º
0º to 45º to
the left
33 mm 50mm
220V ~ 60Hz
CROSS CUT SAW MODE - FIGURE 7.2
Cut radius -45º/0º/+45º
Miter cut to the left:
Cutting width at 90º 120 x 55mm
Cutting width at 45º 65 x 55mm
Cutting Width at 2x 45º (miter double cut) 40 x 23mm
TABLE 6.3 TECHNICAL FEATURES
SAW TABLE MODE - FIGURE 7.1
Table saw 360 x 250mm
Cutting height 0 - 33mm
Parallel fence Tilt -30º up to +30º
TABLE 6.2 TECHNICAL FEATURES
