1 - On/off switch
2 - Operating handgrip
3 - Lock off button
4 - Lock screw upper table top
5 - Dust extraction connection
6 - Lock knob bevelangle
7 - Scale for bevelangle
8 - Head lock down knob
9 - Lock knob mitre angle
10 - Scale for mitre angle
11 - Mounting hole
12 - Lower table top
13 - Guide fence
14 - Saw blade guard
15 - On/off switch
16 - Lower guard
17 - Guide fence
18 - Upper table top
19 - Upper guard
FIGURE 7.2
