6. TECHNICAL FEATURES
* Check Figure 3 ** Thread RP and R compliance with ABNT NBR NM ISO 7:1 or BSP.
TABLE 6.1 – TECHNICAL DATA
MODEL SRS 20 SRS 30 SRS 40 SRS 60 SRS 90 SRS 130 SRS 170 SRS 190 SRS 240
Flow
PCM 20 30 40 60 90 130 170 190 240
/min 566 850 1133 1699,0 2549 3681 4814 5380 6796
m³/h 34,0 51,0 68,0 101,9 152,9 220,9 288,8 322,8 407,8
Maximum
Pressure
barg/psig 15/218
Electric Voltage (V) 220 (Single-Phase)
Nominal Voltage
Consumption
(A) 1,32 1,86 2,0 2,5 3,0 5,0 6,8 7,7 8,2
Conductor (mm²) 2,5
Maximum Distance
Voltage Drop (2%)
(m) 80 75 78 65 55 35 25 25 25
power Consumption (W) 290 410 450 560 660 1100 1500 1700 1800
Refrigerant Fluid Tipo R134a R404a
Fittings Rp/R** 3/4” Rp 3/4” Rp 3/4” Rp 3/4” Rp 1” Rp 1” Rp 1.1/2” Rp 1.1/2” Rp 1.1/2” Rp
Dimensions*
(mm)
A - Altura 600 600 600 600 700 800 975 975 975
B - Portas 475 475 475 475 550 550 765 765 765
C - Frente 412 412 481 481 515 570 725 725 725
Dew point
(@ 7 bar, 38ºC room
temp and compressed
air)
(ºC) 3
Net weight (Kg) 28,8 29,4 33 35 54 73 112 115 117
A
L C
MODEL SRS 280 SRS 340 SRS 450 SRS 600 SRS 890 SRS 1000 SRS 1300
Flow
PCM 280 340 450 600 890 1000 1300
/min 7929 9628 12743 16990 25202 28317 36812
m³/h 475,7 577,7 764,6 1019,4 1512,1 1699,0 2208,7
Maximum
Pressure
barg/psig 15/218
Electric Voltage (V) 220 (Single-Phase)
(Three-Phase) (Three-Phase) (Three-Phase)
220 380 440 220 380 440 220 380 440
Nominal Voltage
Consumption
(A) 10,0 11,4 18,6 18,6 28,0 17,0 14,0 28,0 17,0 14,0 31,2 19,7 17,2
Conductor (mm²) 2,5 4,0 6,0 4,0 2,5 6,0 4,0 2,5 6,0 4,0 4,0
Maximum Distance
Voltage Drop (2%)
(m) 18 20 16 16 30 30 50 30 30 50 30 30 30
power Consumption (W) 2200 2500 4100 4100 4175 4175 7100
Refrigerant Fluid Tipo R404a R22
Fittings Rp/R** 1.1/2” Rp 2” Rp 2” Rp 2” Rp 3” R 3” R 3” R
Dimensions*
(mm)
A - Altura 1112 1325 1325 1325 1545 1545 1545
B - Portas 970 1155 1155 1155 1100 1100 1100
C - Frente 725 853 853 853 893 893 893
Dew point
(@ 7 bar, 38ºC room
temp and compressed
air)
(ºC) 3
Net weight (Kg) 157,5 203 231 286 337 337 328
A
L C
