0099000909-01
SC-1000A
SC-1200A
SSC-1500A
SSC-1000A
SC-600A
Automatic Battery Charger / Cargador de batería automático
Models / Modelos: SC-600A, SC-1000A, SC-1200A,
SSC-1000A, SSC-1500A
READ THE ENTIRE MANUAL BEFORE USING THIS PRODUCT.
FAILURE TO DO SO COULD RESULT IN SERIOUS INJURY OR DEATH.
LEA EL MANUAL COMPLETO ANTES DE UTILIZAR ESTE PRODUCTO.
CUALQUIER FALLA PODRÍA RESULTAR EN SERIAS LESIONES O PODRÍA SER MORTAL.
OWNER’S MANUAL
MANUAL DEL USUARIO
DO NOT RETURN THIS PRODUCT TO THE STORE!
Call Customer Service for Assistance: 800-621-5485
¡NO LO DEVUELVA ESTE PRODUCTO A LA TIENDA!
Llame a Servicios al Cliente para Asistencia: 800-621-5485

Table of Contents

Questions and Answers

  • K
    Kayla HardyJul 30, 2025
    Why is my Schumacher Electric SC-600A Battery Charger making a clicking sound?
    • A
      Ashley RamirezJul 30, 2025
      If your Schumacher Electric Battery Charger makes an audible clicking sound, this could be due to several reasons. The circuit breaker might be cycling because the settings are wrong, so check them. The battery may be defective, so have it checked. There might be shorted battery cables or clamps, which you should inspect and replace if necessary. A severely discharged battery may also cause this, so allow charging to continue until it recovers, but stop after 20 minutes if it persists and have the battery checked. Finally, reverse connections at the battery can cause this, so shut off the charger and correct the lead connections.
  • E
    Eric DiazAug 3, 2025
    How to fix a Schumacher Electric Battery Charger when the connected light is not on?
    • S
      Stephen GonzalezAug 3, 2025
      If the CONNECTED (red) or CHECK (red) light is not on, it could be due to a few reasons: the battery is not connected correctly, the connection to the battery is reversed, or the battery voltage is less than one volt. Check for poor connection to the battery and frame, ensuring the connection points are clean. Rock the clips back and forth for a better connection. Correct the connection if it's reversed. If the voltage is too low, replace the battery or try using a manual charger to bring it above one volt.
  • M
    mark41Aug 7, 2025
    What to do if Schumacher Electric Battery Charger is on but not charging?
    • M
      Mary BushAug 7, 2025
      If the battery is connected and the Schumacher Electric Battery Charger is on, but not charging, the clamps may not be making a good connection. Check for poor connections at the battery and frame, ensure the connecting points are clean, and rock the clamps back and forth for a better connection.
  • A
    Anthony DennisAug 11, 2025
    Why Schumacher Electric Battery Charger will not turn on?
    • L
      Leah DelgadoAug 11, 2025
      If your Schumacher Electric Battery Charger will not turn on when properly connected, the AC outlet may be dead, or there may be a poor electrical connection. Check for an open fuse or circuit breaker supplying the AC outlet. Also, check the power cord and extension cord for a loose-fitting plug.
  • L
    Laurie EvansAug 15, 2025
    Why is the connected red light blinking on my Schumacher Electric SC-600A?
    • L
      lblackAug 16, 2025
      If the CONNECTED (red) light on your Schumacher Electric Battery Charger is blinking, the charger may be in abort mode, or the battery may be faulty. This can happen if the battery doesn't reach full charge within 48 hours, possibly due to a very large battery or a bank of batteries requiring more power than the charger can deliver in that time. To resolve this, reset the charger by unplugging it. Then, select the desired CHARGE RATE and battery type again, if necessary.
  • S
    Sara GreenAug 20, 2025
    What to do if charged green light turns on too fast on Schumacher Electric Battery Charger?
    • Z
      zrobinsonAug 20, 2025
      If the CHARGED (green) light turns on too quickly after connecting the battery to your Schumacher Electric Battery Charger, the battery may already be fully charged or recently charged. Alternatively, the battery may be faulty (sulfated). If the battery is in a vehicle, turn the headlights on for a few minutes to reduce the battery voltage and try charging again. Also, try a lower CHARGE RATE selection. A sulfated battery will eventually accept a charge if you continue charging for a few hours. The CHARGING (yellow) LED will blink. If not, have the battery checked or call customer service.
  • R
    rlambertAug 25, 2025
    What does it mean if indicator lights are lit erratically on Schumacher Electric Battery Charger?
    • C
      Christopher VelasquezAug 25, 2025
      If the indicator lights on your Schumacher Electric Battery Charger are lit erratically, not as explained in the Operating Instructions, a button may have been pressed while the charger was being plugged in. Ensure nothing is touching the control panel, then unplug the unit and plug it in again.

Summary

Important Safety Instructions

Risk of Electric Shock or Fire

General warnings about electric shock and fire hazards during operation.

Personal Precautions

Risk of Explosive Gases

Safety precautions related to explosive gases from batteries.

Preparing to Charge

Risk of Contact with Battery Acid

Hazards and precautions when handling battery acid.

Follow These Steps When Battery is Installed in Vehicle

Follow These Steps When Battery is Outside Vehicle

Spark Near Battery May Cause Explosion

Precautions for preventing sparks and battery explosions when charging externally.

Grounding and AC Power Cord Connections

Risk of Electric Shock or Fire

Safety instructions for grounding and AC power connections.

Operating Instructions

Charging

Step-by-step guide for connecting and operating the charger.

Troubleshooting

Connected (Red) Light Not On

Check (Red) Light Not On

Connected (Red) Light Blinking

Schumacher Electric SC-600A Specifications

General IconGeneral
Input Voltage120V AC
Output Voltage6V/12V
Output Current6A
Charging Amperage6A
Automatic ShutoffYes
Battery TypeAGM, Gel
Cable Length6 ft
Charging ModesFast
