INSTRUCTIONS FOR USE - TENStem eco basic
6.2 Technical data
2-channel electrostimulation device with separate outputs and twelve integrated pro-
grammes (three additional “user programmes” from series C and four additional “user pro-
grammes” from series E).
Voltage supply 6.0 V (4× 1.5 V battery AAA type Micro, e.g. LR03) or 4.8 V
(4x1.2 V battery AAA), approximately 3 hours running time,
depending on selected intensity
Power consumption max. 100 mA (therapy); approx. 60 μA (power down)
Dimensions approx. 140 mm × 64 mm × 28 mm
Weight approx. 96 g (without batteries)
Output current 0–60 mA (on 1 kΩ load)
Pulse shape series A-K positive rectangle with negative component
Pulse shape from series L biphasic rectangular pulse
Pulse shape for P16 positive rectangular pulse
Frequency range 2-100 Hz or 1-120 Hz (from series C)
Pulse width 75–250 μs or 75–300 μs (from series C)
Working conditions Temperature range: 10–40°C, relative humidity: 30-75%, air
pressure: 70–106 kPa
Storage conditions Temperature range: –10–55°C, relative humidity: 10-90%, air
pressure: 50–106 kPa
Service life of the
TENStem eco basic
5 years
6.3 Output pulses
On load 1 kΩ real, series A–K On load ANSI/AAMI standard, series A–K
On load 1 kΩ real, from series L
