Schwaiger DAB 650 - PRODUCT OVERVIEW

35
USER GUIDE
PRODUCT OVERVIEW
2 3 5
7 8 11 12109
14 15 1613
61 4 1
1. SPEAKERS
2. STANDBY BUTTON
3. PRESET BUTTON
4. DISPLAY
5. BACK BUTTON
6. REMOTE CONTROL SENSOR
7. MODE BUTTON
8. INFO/MENU BUTTON
9. VOLUME/SELECT/SNOOZE DIAL
10. SCAN BUTTON
11. BUTTON
12. BUTTON
13. ROD ANTENNA
14. EARPHONE JACK
15. USB 5V
1A Charging Port
16. DC IN SOCKET
