Hardware Overview
Figure 37 SEL-787-3E Wiring Diagram
RX
TX
5 4 3 2 1
9 8 7 6
5 4 3 2 1
9 8 7 6
Port 4 DeviceNet
(Optional)
V–
CAN_L
SHIELD
CAN_H
V+
OUT101
OUT102
OUT103
A01 A02 A03 A04 A05 A06 A07 A08 A09 A10 A11 A12 C01 C02 C03 C04
IRIG-B
-/N+/H
IAW1 IBW1 ICW1 IAW2
TX+
TX–
RX+
RX–
SHIELD
(Optional)
Port 4A EIA-485
IRIG-B Time Source
≤ 1000 m
FO Cable**
1–12 RTDs
Front
Port 3
Optional Input/Output Cards
+
—
+
—
+
—
+
—
+
—
+
—
+
—
+
—
+
—
+
—
10 RTDs
4 Digital Inputs / 4 Digital Outputs
3 Digital Inputs / 4 Digital Outputs / 1 Analog Output
4 Analog Inputs / 4 Analog Outputs
8 Digital Inputs
8 Digital Outputs
IN101 IN102
CONTROL INPUTSINPUT POWER
OUTPUT CONTACTS
SEL-787-3E
Transformer Protection Relay
** SEL Fiber-Optic Cables
240-1506 — 1 m (3.3 ft) ST/ST
240-1507 — 5 m (16.4 ft) ST/ST
240-1508 — 15 m (49.2 ft) ST/ST
Other lengths available by request
Power Supply
110–240 Vac
24–48 Vdc
110–250 Vdc
(Optional
485)
SEL 2812 compatible ST
Fiber-Optic Serial Port
(Optional)
OUT301
OUT302
OUTPUT CONTACTS
(Optional)
IBW2 ICW2
Optional Ethernet (single or dual)
OR
PHASE AND NEUTRAL CURRENTS AND VOLTAGE INPUTS
CURRENT INPUTS
VC N
SEL-2600 Series
External RTD Module
With ST Option
(Optional)
E01
E02 E03 E04
E11
E12 Z01 Z04 Z06 Z07Z05Z02
Z03
Z08 Z09 Z10 Z11 Z12
E10
E09E08E07E06E05
ICW3 IN VA VB
4 Digital Inputs / 3 Digital Outputs
IAW3 IBW3
